• Valve: SV30276TE004
• Valve manufacturer: Sharpe
• Valve type: Gate valve
• Valve material: Stainless Steel 316
• Valve connection: 1/2 in. NPT
• Line size: 0.5
• CV: 17.6
• Pressure: 200 PSI

Enclosures*

• Standard Aluminum enclosure
• Stainless-Steel enclosure
• Class I Div I Groups B,C,D (CSA and IECEx rated)
• Stainless-Steel Class I Div I Groups B,C,D (CSA and IECEx rated)
• IP68 enclosures available*


Control Settings

• Analog (4-20 mA or 1-5 V)
• Modbus (RS485)
• TTL input 0 V (pull to ground)variable positioning


Feedback Options

• None
• 4-20 mA feedback


Other Features

• Manual Override
• 110-240 VAC Power
• Battery Backup (min. 24 VDC power required)
• Isolated Input
• Prewired Turck M12 connector with 20 ft cable
• High Temperature Mounting Kit
