Fairchild
M4000ABP
FAIRCHILD - Pressure Regulators
Model 4000ABP Pneumatic Precision Back Pressure Regulator is a no bleed design regulator that precisely controls system back pressure. With its high flow capacity, the M4000ABP provides fast response and precision control under varying conditions.
Features
• Four set point pressure ranges from 0.5-10 psi, 0.03-0.7 BAR, 3-70 kPa up to 2-150 psi, 0.1-10 BAR, 15-1000 kPa
• Control sensitivity of 1/2" water column allows for use in precision applications
• High flow capacity - responsive performance for precision back pressure or relief applications
• Large relief valve - high exhaust flow
• Aspirator tube compensates for any pressure build up under flow conditions
• Separate control chamber isolates the diaphragm from the main flow and eliminates hunting and buzzing
• Unit construction allows you to service the model 4000ABP without removing it from the line
